How to graph in excel

Business Intelligence

May 28, 2025

Learn to create clear and effective graphs in Excel with tips on data preparation, chart selection, and customization for professional results.

Graphs in Excel make data easy to understand and visually appealing. Here's how to create them:

  1. Prepare Your Data: Organize data in rows/columns, clean it (remove duplicates, fix typos), and convert it into an Excel table for dynamic updates.

  2. Choose the Right Chart: Use bar charts to compare categories, line charts for trends over time, pie charts for parts of a whole (2-6 categories max), and scatter plots for relationships between variables.

  3. Insert a Chart: Select your data, go to Insert > Recommended Charts, and pick the best option. Customize with titles, labels, and colors.

  4. Enhance Your Graph: Adjust gridlines, axis intervals, and formatting for clarity. Use consistent colors and fonts to align with your branding.

  5. Use Dynamic Features: Add slicers, timelines, or interactive dashboards for real-time data exploration.

Quick Tip: Start with clean, well-labeled data and choose a chart that matches your story. For example:

  • Bar Chart: Compare sales by region.

  • Line Chart: Track monthly revenue.

  • Pie Chart: Show market share.

Excel’s tools help you turn raw data into clear, actionable visuals. Ready to get started? Let’s dive in!

Excel Charts and Graphs Tutorial

Excel

Preparing Your Data for Graphing

Before diving into graph creation, it's essential to get your data in order. Organizing, cleaning, and formatting your data into a dynamic table ensures smoother charting and minimizes errors. A well-prepared dataset not only speeds up the process but also guarantees accurate and visually effective results.

Organizing Your Data

The way you structure your data plays a huge role in determining which chart types Excel suggests and how accurately your graphs represent the information. For most common chart types - like column, bar, line, area, surface, and radar - arrange your data in columns or rows. Pie charts require a single set of values paired with labels, while scatter and bubble charts need x-values in the first column, y-values in the second, and an optional third column for bubble sizes if applicable [2].

Clear labeling is critical. Use descriptive headers for each column and row, and for time-based data, stick to actual dates, times, or sequential numbers as row headers [3]. Whenever possible, arrange your data vertically. Excel supports more rows than columns, and many of its tools work better with vertical datasets [3].

Chart Type

Required Data Layout

Column, Bar, Line, Area, Surface, Radar

Data in columns or rows

Pie

One set of data values and one set of labels

XY (Scatter) or Bubble

X values in the first column, Y values in the second, bubble sizes in the third

Stock

Data for volume, opening, high, low, and closing values, plus labels

To avoid issues, steer clear of merging cells. Instead, use Excel's "Center Across Selection" feature [3]. Keep all your data on a single worksheet, and separate raw data from totals to ensure optimal chart functionality.

Cleaning Your Data

Before charting, clean up your dataset. Use Excel's spell checker to catch typos and standardize labels for consistency in chart legends [4]. Duplicate entries can be removed with the "Remove Duplicates" feature, while Excel's text functions help tidy up your data. For example:

  • TRIM removes extra spaces.

  • CLEAN eliminates non-printing characters.

  • SUBSTITUTE replaces unwanted text.

Additionally, functions like LOWER, UPPER, and PROPER ensure uniform capitalization across your dataset [4].

If your data includes numbers stored as text, convert them to numeric format to avoid calculation errors. Similarly, standardize date formats to prevent timeline misinterpretations [4]. For datasets with combined information (like full names in one column), consider splitting them into separate columns for flexibility. Merge columns only when it’s logical and necessary [4].

Converting Data into an Excel Table

Transforming your data into an Excel table is a game-changer for creating dynamic charts. Tables have the ability to automatically update your charts as new data is added - saving you from manually adjusting chart ranges [5][6]. To convert your data into a table, simply select your range and press Ctrl+T [5]. This turns static data into a dynamic structure that Excel manages more effectively.

Tables make it easy to sort and filter data, add new records, and ensure your charts stay up-to-date automatically. Unlike static data ranges, tables expand as you add rows or columns, keeping your charts current without extra work [6]. They also simplify writing formulas by letting you reference columns by name instead of cell addresses [5].

Excel tables come with built-in formatting styles and enhanced data validation options to keep your data looking polished [7]. With their automatic expansion feature, tables grow to include new entries, ensuring your charts always reflect the full dataset [6].

Once your data is cleaned, organized, and converted into a table, you’re all set to start creating graphs in Excel.

Creating Graphs in Excel: Step-by-Step Guide

Once your data is clean and organized in a table format, you're ready to turn it into clear and effective charts. Excel offers several ways to create graphs, ranging from automated suggestions to manually selecting specific chart types. The trick is knowing how to select your data and make the most of Excel's built-in tools to choose the best visualization for your needs.

Inserting a Graph Using Recommended Charts

Excel's Recommended Charts feature simplifies the process by suggesting chart types that best fit your data. This tool not only saves time but also helps you avoid common mistakes in data visualization.

To use this feature, start by selecting at least one cell within your data range. If your dataset isn't continuous, you can select nonadjacent cells or ranges - just make sure your selection forms a rectangle.

Once your data is selected, go to Insert > Recommended Charts. This opens a window displaying a list of suggested chart options tailored to your data. You can preview each option by clicking on it. Once you find a chart that works well, select it and click OK. Excel will insert the chart into your worksheet. From there, you can use the options next to the chart - Chart Elements, Chart Styles, and Chart Filters - to customize it further.

Choosing the Right Graph Type

Picking the right chart type is essential for presenting your data effectively. As Kelly L. Williams, CPA, Ph.D., MBA, and Associate Professor of Accounting at Middle Tennessee State University, puts it:

"Data visualization transforms raw data into graphical representations, making complex financial information more accessible and understandable." [1]

Each chart type serves a specific purpose. For instance:

  • Bar charts are great for comparing values, ranking items, or identifying patterns. They can also be sorted or filtered for added clarity.

  • Line charts are ideal for tracking trends or changes over time, especially when your categories represent time periods.

  • Pie charts work best when showing two values as parts of a whole, but they can become confusing with more than 5–6 categories.

  • Scatter plots are perfect for exploring relationships or correlations between variables.

Here's a quick reference guide:

Chart Type

Best Use Cases

When to Avoid

Column/Bar Chart

Comparing categories, rankings, survey results

Avoid for time trends

Line Chart

Tracking trends over time, monitoring performance

When comparing unrelated categories

Pie Chart

Showing parts of a whole (2-6 categories max)

For more than 6 categories or trends

Scatter Plot

Analyzing relationships, finding correlations

When categories lack numerical links

Pie charts, in particular, should be used sparingly. They work well for simple comparisons but can make complex data harder to interpret. For situations where you need to show how categories contribute to a total, a waterfall chart might be a better option. For example, in October 2024, the Journal of Accountancy used a waterfall chart to clearly display revenue additions, cost reductions, and net income. [1]

Customizing Graph Data Ranges

Excel gives you plenty of flexibility when it comes to controlling what data appears in your charts. If your data isn't formatted as a table, you can manually select specific rows, columns, or cells. For adjacent columns, click and drag across the headers. For nonadjacent data, hold Ctrl (or Command on Mac) and click each cell or range you need.

If your data is in a table but you want to select nonadjacent sections, you'll need to convert the table back to a normal range first. Place your cursor in the table, then go to the Table tab and select Convert to Range.

Already created your chart but need to adjust the data? No problem - right-click the chart and choose Select Data. This opens a task pane where you can update the data range. To add a new data series, navigate to Data > Setup > Add Field, pick the relevant cells, and apply the changes. Excel makes it easy to refine your chart as your data evolves.

Customizing and Enhancing Graphs

Customizing your charts in Excel transforms raw data into a meaningful and visually appealing story. Basic graphs often need adjustments to improve clarity and aesthetics, making your data easier to understand and more engaging.

Adjusting Axes and Gridlines

Gridlines provide a helpful framework for charts, extending from the axes to guide viewers in tracking data points accurately. When used effectively, they enhance readability without overwhelming the visual presentation.

To adjust gridlines, select your chart, navigate to the Design tab, and click Add Chart Element. From there, choose Gridlines and select your preferred option. You can toggle between major and minor gridlines - major ones align with primary tick marks, while minor ones add finer detail [9]. If the chart looks too busy, you can remove gridlines by selecting them and pressing DELETE [9].

For better readability, adjust axis intervals to declutter the chart [10]. Click on an axis, go to the Format tab, and select Format Selection. Under Axis Options, you can modify tick marks and label positions. For example, if your horizontal axis is crowded, consider displaying every third month instead of every data point.

When category names are lengthy and overlap, open the Format Axis dialog box, select Text Options, and adjust the text direction or apply a custom angle to improve the layout [10]. With these adjustments, your chart becomes more visually accessible and easier to interpret.

Using Chart Titles, Labels, and Legends

A well-crafted chart title serves as a headline, drawing attention and setting expectations for the data. Be specific with your titles - examples like "Q4 Revenue Increased 23% Despite Market Challenges" or "Customer Satisfaction Scores Hit Record High in March 2024" tell a clearer story.

To add or edit titles, click on your chart, go to the Design tab, and select Add Chart Element > Chart Title. You can position the title above the chart, overlay it, or place it elsewhere. Customize its font, size, and color to align with your branding or improve readability [12].

Axis titles are essential for clarifying what the data represents, such as units, time periods, or categories [13]. Add them by selecting Chart Elements > Axis Titles and specifying whether you want titles for the primary horizontal, vertical axis, or both.

Data labels display exact values directly on chart elements, making them ideal for presentations where precision is key. However, use them sparingly - too many labels can clutter the chart. They work best with fewer than six data points or when specific values are central to your message [13].

Legends explain the meaning of colors, lines, or patterns in your chart. Position the legend so it doesn’t overlap with the chart itself. Experiment with placing it at the top, bottom, left, or right to find the most effective layout [11].

For dynamic charts, link chart and axis titles to worksheet cells. This ensures titles update automatically when the underlying data changes, keeping your visuals current and accurate [13].

Applying Visual Enhancements

Visual consistency takes a chart from basic to professional. Thoughtful use of colors, fonts, and formatting ensures your chart supports the data rather than distracting from it.

As Edward Tufte, a respected voice in data visualization, once said:

"Data graphics should emphasize the data's core message." [15]

Color plays a significant role in readability. Stick to a limited palette that ensures high contrast, avoiding overly complex or distracting hues [14]. While using your organization's brand colors is a good practice, prioritize clarity. Differentiating colors for data series makes it easier for viewers to distinguish between categories or time periods.

Excel's built-in chart styles offer pre-designed color schemes and formatting options. Access these styles through the Design tab to quickly apply professional-looking adjustments that enhance readability.

Simplify your chart by removing unnecessary elements like background lines, excessive gridlines, or borders [16]. A clean, uncluttered design ensures your data remains the focal point.

For bar charts, fine-tune the gap width and series overlap to improve comparisons. Right-click on the bars, select Format Data Series, and experiment with these settings. Narrower gaps can make comparisons clearer, while wider gaps reduce visual density if the chart feels crowded.

In 2020, Colliers Valuation & Advisory Team streamlined their chart formatting process by adopting automated tools. This allowed them to create and format complex charts, such as Marimekko and Waterfall charts, with a single click. The time saved was redirected to more strategic tasks like advanced data analysis [16].

Lastly, arrange axes in descending or chronological order to simplify the chart's flow. Logical ordering helps viewers process information quickly, reducing cognitive effort and ensuring your customizations effectively communicate your insights [16].

Tips for Professional Graphing in Excel

Once you've got a handle on preparing your data and creating basic charts, it's time to take things up a notch. Polished, professional-looking graphs are essential for presentations, reports, and client meetings. They do more than just display data - they communicate your message effectively. Here are some tips to help you create consistent, high-quality visuals in Excel.

Maintaining Consistency with Branding

Keeping your charts aligned with your organization's branding strengthens your visual identity. Excel provides several tools to ensure your graphs reflect your company's style.

  • Save a Chart Template: By right-clicking on a chart and selecting "Save as Template", you can lock in your company’s colors, fonts, and layout. This way, every time you use the template, your charts will maintain the same branding.

  • Customize Document Themes: On the Page Layout tab, you can modify the default color palette by selecting Themes. This allows all charts in the document to automatically adopt your company’s colors. If a chart’s colors don’t match the workbook’s theme, simply right-click the chart area and select Reset to Match Style to fix it[17].

  • Manual Adjustments: Fine-tune individual elements like axis colors, background fills, and borders to align with your branding. Using consistent fonts for titles, labels, and legends also helps create a professional look.

These techniques work hand-in-hand with broader customization strategies, ensuring your charts always look cohesive.

Optimizing Graphs for Presentations

Once your charts are styled consistently, focus on making them presentation-ready. Good presentation charts are clear, easy to read from a distance, and visually impactful - whether projected on a screen or printed.

  • Stick to a uniform color scheme, font sizes, and formatting to keep the attention on your data.

  • Declutter your charts by removing unnecessary elements that don’t support your key message. Use concise, horizontal labels for better readability, and avoid diagonal text.

  • Use color strategically to emphasize important points. For example, solid bars can represent actual values, while hatched patterns can indicate forecasts. Highlight positive outcomes in green and negative ones in red for quick visual cues.

  • Scale your charts appropriately to reflect the importance of each category. Make sure your axes start at logical values to avoid misleading the viewer. When naming charts, include the subject, key measures (with units), and the time period for clarity.

By following these steps, your charts will not only look professional but also convey your message effectively[8].

Using Dynamic and Interactive Elements

To take your charts to the next level, consider adding dynamic and interactive features. These elements allow users to explore data in real time, making them ideal for ongoing reporting and analysis. Interactive dashboards, for example, can consolidate multiple views into a single, user-friendly format.

  • Slicers and Timelines: Add slicers to your PivotTables or PivotCharts by selecting Insert Slicer under the PivotTable Analyze tab. These tools provide quick filtering options and can even connect to multiple tables for broader data control.

  • Excel Tables: Using Excel Tables ensures your charts update automatically as new data is added.

  • Named Ranges with OFFSET and COUNTA: For more advanced dynamic ranges, Named Ranges can be used, though Excel Tables are generally simpler and more efficient.

  • Interactive Dashboards: Ann K. Emery’s tutorial is a great example of how to create a dashboard using YouTube statistics. By combining pivot tables, pivot charts, and slicers, her dashboard allows users to filter data by month, traffic source, and more. It also features clear titles, dates, brand colors, and plenty of whitespace for a clean, professional look[19].

Before adding interactive elements, make sure your data is clean and well-organized. Remove blank rows, fix inconsistent formatting, and ensure related data is grouped in adjacent columns. This preparation minimizes errors and ensures smooth functionality. Interactive dashboards are especially useful for technical audiences who need a centralized view of key metrics[18][19].

Conclusion: Getting the Most from Excel Graphs

Creating effective Excel graphs is all about turning raw data into meaningful insights through smart design and preparation. It starts with well-organized data and thoughtful chart selection, ensuring the visuals align with the story you’re trying to tell. For instance, line charts are perfect for showing trends over time, while column charts work well for comparing categories. The key is to match the chart type to your message.

Keep it simple - complexity often distracts rather than clarifies. Remove unnecessary borders, gridlines, tick marks, and legends when direct labels can do the job better. These small tweaks pave the way for cleaner, more professional visuals.

Use contrast wisely to highlight the most important data points while keeping less critical elements muted. This ensures your audience focuses on what truly matters. Additionally, staying consistent with your company's graphic standards not only enhances readability but also boosts your professional credibility. In fact, 78% of finance professionals view compliance with branding guidelines as essential for their deliverables [16].

Think about your audience when designing graphs. Arrange data logically, ensure clean alignment, and leave enough white space to make your visuals easy to read. Avoid clutter by removing background lines and unnecessary axes - it’s all about clarity and simplicity [20].

Excel graphs are more than just charts; they’re tools for uncovering trends and driving decisions. By adhering to these design principles, you can create visuals that respect your audience’s time while maintaining the integrity of your data [20].

As Kelsey Berteaux, Sr. Legal Operations Analyst at DigiCert, Inc., puts it:

"A well-designed graph in Excel can transform raw data into compelling insights. By applying a few design principles, legal operations professionals can create visuals that drive better decision-making. Thoughtful data visualization is not just about aesthetics - it's about respect for your audience and your data." [20]

With tools like Querio, mastering these Excel fundamentals becomes even more impactful. Beyond creating visually appealing charts, the goal is to communicate insights that lead to better business decisions. Combine these principles with Querio's features to consistently deliver graphs that inspire action and drive results.

FAQs

What mistakes should I avoid when creating charts in Excel?

Common Mistakes When Creating Charts in Excel

Creating charts in Excel can be a powerful way to present your data visually, but a few common mistakes can make your charts harder to understand.

One frequent misstep is choosing the wrong chart type. For instance, using a pie chart for data that would be better represented with a line or bar chart can muddle the message you're trying to convey. Always pick a chart type that aligns with the story your data is telling.

Another issue is adding too much clutter. Elements like unnecessary gridlines, overly bright colors, or flashy 3D effects can distract from the main point of your chart. A clean, simple design helps your data stand out and keeps the focus where it belongs.

Lastly, forgetting to label your axes and data points clearly can leave your audience guessing. Missing or unclear labels make it difficult to interpret your chart, reducing its effectiveness. Clear and precise labels ensure your audience understands the data you're presenting.

By avoiding these pitfalls, you can create charts that are not only visually appealing but also effectively communicate your data.

How can I make my Excel graphs match my organization's branding?

To make sure your Excel graphs match your organization's branding, focus on using consistent colors, fonts, and styles that follow your brand guidelines. You can adjust these settings in the "Format" tab to create a unified and professional appearance.

To achieve a polished and well-organized look, take advantage of Excel's alignment tools. For example, you can select multiple graphs, head to the "Format" tab, and use options like Align Left, Align Center, or Distribute Horizontally to position them evenly.

Lastly, keep your graphs simple by removing any unnecessary elements, such as gridlines or background images. This helps keep the attention on your data and ensures your presentation looks clean and professional.

What are the advantages of using Excel tables for updating charts dynamically?

Using Excel tables for dynamic chart updates comes with some great perks. For starters, when you add new data to a table, the connected chart updates automatically - no need to manually tweak anything. This keeps your charts accurate and current as your dataset expands.

On top of that, Excel tables make sorting and filtering data a breeze. This allows you to zero in on specific trends or insights without hassle. By cutting down on errors and streamlining data management, dynamic tables not only save you time but also make your data analysis and reporting much more efficient.
